Yamaha YXZ1000 MT72 72" Front Long Travel Suspension Kit, Stock Knuckles
Purchase Options
Final fulfillment timing is confirmed after checkout. Contact AVID before ordering if you have a firm deadline.
Product Details
Overview & Included Items
YXZ1000 MTR72 Front Mid-Travel SR Kit – 72” Width
After years of refining our LT and XC packages for the YXZ1000, we created the highest-performing 72” mid-travel kit on the market. This system delivers 4” of added width per side, handcrafted from 4130 Chromoly and TIG-welded for unmatched strength and reliability.
Key Features
- True 72” stance – 4” wider per side for maximum stability.
- 4130 Chromoly construction – lightweight, race-proven durability.
- 7/8” “stem cup” pivots – signature AVID design for ultimate strength.
- 3/4” heim joints – adds safety plus easy camber/caster adjustment.
- Relocated front shocks – optimized mounting angle for smoother travel.
- 7/8” uniball bearings – eliminates the weak factory ball joints with direct bolt-in strength (factory spindle only).
- 100% bolt-on install – no cutting, welding, or fabrication required.
What’s Included
- Complete front upper & lower control arms (left and right)
- All uniballs, rod ends, bushings, and misalignment spacers
- 300M spindle adapters for maximum durability
Looking for Race Geometry?
Check out our 72” MTR Race Kit for aggressive driving and corrected geometry. Note: Race arms mount to our proprietary race spindle and are not cross-compatible with this mid-travel kit.
Applications & Fitment
Vehicle Applications
-
Yamaha YXZ1000R 2022
SS XT-R
-
Yamaha YXZ1000R 2025
SS XT-R EPS
-
Yamaha YXZ1000R 2017
SS
-
Yamaha YXZ1000R 2021
SS Se2
-
Yamaha YXZ1000R 2017
EPS SE
-
Yamaha YXZ1000R 2021–2022
SS Std
-
Yamaha YXZ1000R 2025
SS EPS
-
Yamaha YXZ1000R 2023–2024
SS EPS XT-R
-
Yamaha YXZ1000R 2023–2024
MT EPS Std
-
Yamaha YXZ1000R 2021–2022
MT Std
-
Yamaha YXZ1000R 2025
Mt EPS
-
Yamaha YXZ1000R 2016
Eps-Se
-
Yamaha YXZ1000R 2017
SS SE
-
Yamaha YXZ1000R 2021
SS Se1
-
Yamaha YXZ1000R 2021
SS Se3 Cal
-
Yamaha YXZ1000R 2023–2024
SS EPS Std
Specifications
- Riding use
- Sand Dunes, All-Terrain
- Main construction
- Chromoly
- Position / component
- Front control arms
- Overall width
- 72"
