ADS Mesa 2.5" Coilovers - Front 100ADS-10128

ADS ADS Shocks SKU 100ADS-10128

Purchase Options

Price $1,662.45

Available to order

Total $1,662.45 Current selection

Complete the required options to confirm your configuration and price.

Final fulfillment timing is confirmed after checkout. Contact AVID before ordering if you have a firm deadline.

My AVID Garage

Save to Planned Build

ADS Mesa 2.5" Coilovers - Front 100ADS-10128

Saving does not reserve inventory, place an order, or begin a payment plan.

Loading your Garage…
Contact AVID About Fitment

Product Details

Overview & Included Items

ADS Mesa 2.5" Coilovers - Front 100ADS-10128

The ADS Mesa 2.5" Coilovers - Front 100ADS-10128 is an ADS factory-replacement shock identified by manufacturer part number 100ADS-10128. 2.5" Mesa IFP Shock, 22'+, Tundra 2.0" - 3.0" Lift.

What This Means on the Vehicle

  • Product identity: The ADS part number is preserved as 100ADS-10128.
  • Application: 2022-2024 Tundra/ Sequoia.

Vehicle Fitment

  • 2022-2024 Tundra/ Sequoia

Key Features

  • Product type: Coilover

Specifications

  • Collapsed Length: 16.93
  • Body Diameter: 2.5
  • Cylinder Diameter: 2.5
  • Extended Length: 22.51
  • Lower Mount Type: Eyelet
  • Mounting Hardware Included: Yes
  • Shaft Material: Hard-chrome plated steel
  • Shaft Diameter: 0.875
  • Stroke: 5.58
  • Strut Mount Insulator(S) Included: No
  • Upper Mount Type: Mounting Plate
  • Travel Length: 5.58
Applications & Fitment

Applications With Conditions

  • Toyota Tundra 2022–2026

    Platinum

    Requirements
    Provides 2-3 (in) Front Lift|Aftermarket Upper Control Arms Required
  • Toyota Tundra 2022–2026

    SR5

    Requirements
    Provides 2-3 (in) Front Lift|Aftermarket Upper Control Arms Required
  • Toyota Tundra 2022–2026

    Capstone

    Requirements
    Provides 2-3 (in) Front Lift|Aftermarket Upper Control Arms Required
  • Toyota Sequoia 2023–2026

    Platinum

    Requirements
    Provides 2-3 (in) Front Lift|Aftermarket Upper Control Arms Required
  • Toyota Sequoia 2023–2026

    Capstone

    Requirements
    Provides 2-3 (in) Front Lift|Aftermarket Upper Control Arms Required
  • Toyota Tundra 2022–2026

    1794 Edition

    Requirements
    Provides 2-3 (in) Front Lift|Aftermarket Upper Control Arms Required
  • Toyota Sequoia 2023–2026

    TRD Pro

    Requirements
    Provides 2-3 (in) Front Lift|Aftermarket Upper Control Arms Required
  • Toyota Tundra 2022–2026

    TRD Pro

    Requirements
    Provides 2-3 (in) Front Lift|Aftermarket Upper Control Arms Required
  • Toyota Sequoia 2025–2026

    1794 Edition

    Requirements
    Provides 2-3 (in) Front Lift|Aftermarket Upper Control Arms Required
  • Toyota Sequoia 2023–2026

    SR5

    Requirements
    Provides 2-3 (in) Front Lift|Aftermarket Upper Control Arms Required
  • Toyota Sequoia 2023–2026

    Limited

    Requirements
    Provides 2-3 (in) Front Lift|Aftermarket Upper Control Arms Required
  • Toyota Tundra 2022–2026

    Limited

    Requirements
    Provides 2-3 (in) Front Lift|Aftermarket Upper Control Arms Required

Confirm These Applications With AVID

  • Toyota Tundra 2013–2021

    Platinum

  • Toyota Tundra 2019–2021

    TRD Pro

  • Toyota Tundra 2014–2021

    1794 Edition

  • Toyota Tundra 2014–2021

    SR5

  • Toyota Tundra 2000–2021

    Limited
